Pir Sensor Led Tube 19W 4ft Tube Lights

Pir Sensor Led Tube 19W 4ft Tube Lights

  • Model Number:
  • SYH-T08-012-288A-IR-G02
  • Power:
  • 19W
  • Size:
  • D26*1200MM
  • Input Voltage:
  • AC100-240V
  • Material:
  • Alloy Aluminum housing & PC Cover
  • Color Temperature:
  • 5000-5500K


General Introduction

This PIR Sensor Led Tube uses SMD LED3528 as light source and there are 600mm(2 feet), 900mm(3 feet), 1200mm(4 feet), 1500mm(5 feet) available.With longer lifespan(>50,000hours), higher brightness and less toxic substance, PIR sensor LED tube can be widely used in underground parking lot, tenement corridor, passageway, etc. This type of PIR Sensor Led Tube adopts the standard G13 socket and works with AC100-240V voltage input and DC48-56V voltage output.




PIR Sensor LED Tube Details Photo

Pir Sensor Led Tube 19W 4ft Tube Lights sm led2835

Pir Sensor Led Tube 19W 4ft Tube Lights isolate power supply

Pir Sensor Led Tube 19W 4ft Tube Lights milky pc cover

Pir Sensor Led Tube 19W 4ft Tube Lights aluminum alloyed housing

Pir Sensor Led Tube 19W 4ft Tube Lights end caps

Pir Sensor Led Tube 19W 4ft Tube Lights wires


PIR Sensor LED Tube Features

PIR Sensor LED Tube 19w 4ft tube lights with beveled end caps design

Single LEDs of 8-9lumen with 5 years warranty

Isolated power supply of 86% power conversion efficiency

Frosted lenses PC cover of 0.85-0.88 light transmittance

PIR sensor LED tube for 5-7M sensing detection area

PIR Sensor LED Tube Application

Pir Sensor LED Tube can be applied in indoor LED lighting, places as park lot, passageway, tenement corridor,etc.

led tube interior application

PIR Sensor LED Tube Parameters

Model NO.

SYH-T08-012-288A-IR-G02

Optical Parameters

Light Source

SMD LED3528

Luminous Flux(lm)

1800

CCT(K)

5000-5500

CRI(Ra)

70

Beam Angle

120°-160°

Light Attenuation ratio (%)

Less than 10% in 3 years

LED Quantity

288

Electrical Parameters

Input Voltage(V)

AC100-240V

Frequency(Hz)

50/60HZ

Output Voltage(V)

DC48-56V

Total Power(W)

19

Power Factor

>0.9

Lifespan (Hrs)

>50,000

Dielectric Voltage Withstand Test

3750Vac/60s

Structural Parameters

Material

Aluminum housing &PC cover

Size(mm)

Φ26×1200

Length(mm)

1200

Net Weight(g)

320

Integrated Parameters

Operating Temperature

-10°-40°

Storage Humidity

-40°-85°

Safety Requirement

/

Environmental Directives

RoHS


PIR Sensor LED Tube Installation

PIR Sensor LED Tube Light Wiring Diagram:

Pir Sensor Led Tube wiring diagram

1) Turn off electric power before LED Tube Lights installation

2) For refitting old fluorescent lamp with a single-side-and-on-end-shortcut power-input LED tube, please re-connect your wire as the following diagram.



Pir Sensor Led Tube installation diagram

3) For diagram above please remove traditional starter and replace with LED starter; and one end of LED tube lights should be short cut. Now your LED tube lighting is ready to work.


PIR Sensor LED Tube Package

led tube packing way

Concentrated on LED Tubes

Specialized in producing, researching, and developing all types of LED tubes for around 5 years, we have already won trust and favor from customers at home and abroad.


Production Capability

With a 30,000 square meter workshop equipped with advanced machines and over 520 skilled workers, our production capability has reached 1500000 pieces of LED tube lights per month.


R&D Strength

Professional R&D team to guarantee the stable performance of products:

Chip & Packaging Team

Illuminating Efficiency Team

Electrical Engineering Team

Electronic Engineering Team

Hardware Structure Team

Industrial Design Team


Product Quality

Syhdee Manufactory has passed Germany TUV Rheinland and DEKRA Quality Management System certification.

Syhdee LED tubes complied with VDE,TUV, UL, FCC, DLC, SAA, C-Tick, CE&RoHS, Erp, PSE directives, etc.


Factory Direct Price

We are the manufacturer of LED tubes, which enables us to offer our customers factory direct price. Meanwhile good relationship with our material suppliers, skilled staff and advanced facilities make it possible for us to quote the most competitive price.


LED Tube OEM&ODM Project

As one professional LED tube supplier in China, we can offer the turnkey LED tube solutions for our customers. OEM&ODM project is well available.


Warning

Overall energy efficiency and light distribution of any installation that uses such lamps are determined by the design of the installation.
